PELATIHAN ELECTRICAL POWER SYSTEM PROTECTION

TRAINING ELECTRICAL POWER SYSTEM PROTECTION

INTRODUCTION PELATIHAN ELECTRICAL POWER SYSTEM PROTECTION

After completion this training participants will have gained a theoretical and applied understanding of power system protection. The performance of instrument transformers, transducers, protective relays, and circuit breakers is first addressed. These devices are then integrated into coordinated protective systems for generators, transformers, transmission lines, reactors, capacitor banks, system buses, etc. Although basic protection concepts are hardware-independent, the application of electromagnetic, solid state, and microprocessor-based relays will also be discussed. Trade-offs between reliability, selectivity, speed, simplicity, and economy are emphasized. This training is designed to them who want to know on electrical power system protection.

MATERIAL OUTLINE TRAINING ELECTRICAL POWER SYSTEM PROTECTION

Review:
- system protection philosophies,
- system grounding,
- circuit breakers,
- fuses.
Relay input sources:
- VTs,
- CTs,
- CVTs,
- CCVTs,
- optical voltage and
- current transducers.
Fundamental protection concepts:
- time-inverse,
- differential,
- directional impedance, etc.
Generator protection
- differential,
- negative sequence,
- loss of excitation,
- out of step, etc
Motor protection
- ground fault,
- locked rotor,
- undervoltage,
- phase rotation, etc
Bus, reactor, capacitor bank protection.
Transformer protection
- differential,
- sudden pressure,
- over temperature,
- low oil, etc
Line protection
- directional comparison,
- blocking,
- unblocking,
- transfer trip, etc
System stability, reclosing, and load shedding.
Communications
- pilot wire,
- power line carrier,
- microwave,
- fiber optics
- SCADA, etc.
Discussion and cases study

TRAINING INSTRUCTOR

Instruktur yang mengajar pelatihan Electrical Power System Protection ini adalah instruktur yang berkompeten di bidang Electrical Power System Protection baik dari kalangan akademisi maupun praktisi.

Jadwal Pelatihan Transform-mpi.com 2025 :

Batch 1 : 30 – 31 Januari 2025
Batch 2 : 13 – 14 Februari 2025
Batch 3 : 11 – 12 Maret 2025
Batch 4 : 16 – 17 April 2025
Batch 5 : 15 – 16 Mei 2025
Batch 6 : 25 – 26 Juni 2025
Batch 7 : 16 – 17 Juli 2025
Batch 8 : 6 – 7 Agustus 2025
Batch 9 : 3 – 4 September 2025
Batch 10 : 8 – 9 Oktober 2025 || 29 – 30 Oktober 2025
Batch 11 : 13 – 14 November 2025 || 25 – 27 November 2025
Batch 12 : 15 – 16 Desember 2025

Catatan : Jadwal dapat menyesuaikan dengan kebutuhan anda.

Biaya dan Lokasi Pelatihan :

Jakarta :
Bandung
Yogyakarta
Surabaya
Malang
Bali
Lombok

Catatan : Biaya diatas belum termasuk akomodasi/penginapan. Apabila ada pertayaan mengenai materi, biaya, lokasi, jadwal dan penawaran lainnya, hubungi kami di nomor CS kami.
