Pelatihan Electrical Maintenance Low and Medium Voltage

TRAINING Tentang Electrical Maintenance Low and Medium Voltage

PELATIHAN ELECTRICAL MAINTENANCE LOW AND MEDIUM VOLTAGE

Description Training Tentang Electrical Maintenance Low and Medium Voltage

The backbone of many electric power systems is the medium voltage distribution system. Typically operating at voltages ranging from 2,400 to 34,500 Volts, voltage stress, corona, surges and protection of equipment all create unique challenges in design, equipment selection, operation and engineering. This 2 day class takes you through the basics of medium voltage power systems including components,equipment, design and operation problems as well as protection of medium voltage systems.

Purpose Pelatihan Electrical Maintenance Low and Medium Voltage

Setelah selesai mengikuti kursus ini, peserta diharapkan akan mengerti dan memahami masalah Audit sampai pada penerapan konsep Power Management System. Dimana hal itu diperlukan oleh perusahaan sebagai suatu komponen pendukung kegiatan produksi untuk menjamin ketersediaan energi listrik dengan efisien dan murah.

Outline Training Electrical Maintenance Low and Medium Voltage

1. MEDIUM VOLTAGE SAFETY
   • Electrocution at Low vs. Medium Voltage, Arc Flash,
   • Qualified Person, Approach Boundaries
2. TYPES OF MEDIUM VOLTAGE SYSTEMS
   • Utility and Industrial One lines, Reliability Requirements,
   • Overhead and Underground Systems, Regulated Systems
3. MEDIUM VOLTAGE CABLE
   • Copper vs. Aluminum Design, Voltage Ratings
   • Insulation Ratings, 100%, 133%, 173% Insulation Levels,
   • Shielding Requirements, Electric Fields, Terminating MV
   • Conductors, Orientation of Overhead Lines
4. MEDIUM VOLTAGE SUBSTATION TRANSFORMERS
   • Core and Coil Design, Aluminum and Copper Windings
   • Tank Construction, Loss Evaluation, Efficiency, Regulation
5. SPOT NETWORKS
   • Spot Network Design, Network Protectors, Network Protector
   • Relay Operation, Directional Protection Requirements
6. PARTIAL DISCHARGE
   • Corona, Surface Tracking, Voltage Stress, Sensing Partial
   • Discharge, Component Failure
7. GROUNDING MEDIUM VOLTAGE SYSTEMS
   • Resistance Grounding, Solid Grounding, Ungrounded Delta
   • Charging Current, Effect of Ground Faults on Delta Voltage
8. SURGE PROTECTION
   • Lightning and Switching Surges, Classes of Surge Arresters
   • MCOV Ratings – (Maximum Continuous Operating Voltage)
   • TOV – (Maximum Temporary Over Voltage Capability),
   • Protective Characteristics, Surge Arrester Selection, Energy
   • Capability, Effect of Grounding on Arrestor Selection,
   • Insulation Coordination,
9. CURRENT TRANSFORMER APPLICATIONS
   • Ratings, Selection Process, Accuracy, Saturation, Excitation
   • Curves, Burden Calculation, Momentary Ratings
10. MEDIUM VOLTAGE CIRCUIT BREAKERS
    • Vacuum, Air, Oil, SF6 Designs, Symmetrical Interrupting
    • Rating, K-Rated Voltage Factor, Close and Latch Capability
11. RECLOSERS
    • Application on Feeder Circuits, Recloser Settings
    • Continuous Current and Interrupting Ratings
12. MEDIUM VOLTAGE FUSES
    • Medium Voltage Switches, Load Rating, Close and Latch
    • Rating, Short Time Rating, Expulsion vs. Current Limiting
    • Fuse Characteristics, E and R Rated Fuses, Fuse Cutouts
13. MEDIUM VOLTAGE PROTECTION CONCEPTS
    • Medium Voltage Protection, Relays, Circuit Breakers, R and
    • E rated Fuses, Short Circuit vs. Overcurrent Protection
14. DISTRIBUTION FEEDER PROTECTION
    • Protection with Fuses – 300%, Overcurrent Protection with
    • Relays – 600%, Short Circuit Damage Characteristics, Relay
    • “Reach” for End of Line Faults
15. ROTATING MACHINERY PROTECTION
    • Requirements, Decrement Curves, Thermal Damage Curves,
    • Reactive, Capability Curves, Differential Protection
16. MEDIUM VOLTAGE MOTOR CONTROLLERS
    • Protection Requirements, Motor Management Relays, Circuit
    • Breaker Protection, Relaying, Class R Rated Fuses
17. TRANSFORMER PROTECTION
    • ANSI C57 Thru Fault Curves, Impact of Transformer Winding
    • Configuration, Overview of Differential Protection, Inrush and
    • Harmonic Restraint
18. Peserta Training Electrical Maintenance Low and Medium Voltage
    • D3 atau SLTA yang berpengalaman kerja minimal 3 tahun, dan atau setara.
    • Teknisi, Operator dan Supervisor didalam bidang instrumentasi, maintenance dan operasional.
    • Mereka yang dalam tugasnya berhubungan dan atau terkait dengan materi kursus.

Metode Training Electrical Maintenance Low and Medium Voltage

Presentasi, diskusi, dan studi kasus

Instruktur Training Electrical Maintenance Low and Medium Voltage

Instruktur yang mengajar pelatihan Electrical Maintenance Low and Medium Voltage ini adalah instruktur yang berkompeten di bidang Electrical Maintenance Low and Medium Voltage baik dari kalangan akademisi maupun praktisi.

Jadwal Pelatihan Transform-mpi.com 2025 :

• Batch 1 : 30 – 31 Januari 2025
• Batch 2 : 13 – 14 Februari 2025
• Batch 3 : 11 – 12 Maret 2025
• Batch 4 : 16 – 17 April 2025
• Batch 5 : 15 – 16 Mei 2025
• Batch 6 : 25 – 26 Juni 2025
• Batch 7 : 16 – 17 Juli 2025
• Batch 8 : 6 – 7 Agustus 2025
• Batch 9 : 3 – 4 September 2025
• Batch 10 : 8 – 9 Oktober 2025 || 29 – 30 Oktober 2025
• Batch 11 : 13 – 14 November 2025 || 25 – 27 November 2025
• Batch 12 : 15 – 16 Desember 2025

Catatan : Jadwal dapat menyesuaikan dengan kebutuhan anda.

Biaya dan Lokasi Pelatihan :

• Jakarta :
• Bandung
• Yogyakarta
• Surabaya
• Malang
• Bali
• Lombok

Catatan : Biaya diatas belum termasuk akomodasi/penginapan. Apabila ada pertayaan mengenai materi, biaya, lokasi, jadwal dan penawaran lainnya, hubungi kami di nomor CS kami.

Fasilitas Pelatihan di transform-mpi.com:

1. Penjemputan dari Hotel/Bandara/Stasiun/Terminal.
2. Training Kit (Dokumentasi photo, Blocknote, ATK, Flashdisk, dll).
3. Transportasi Peserta ke tempat pelatihan.
4. 2x Coffe Break & 1 Lunch (Makan Siang).
5. Training Room Full AC and Multimedia.
6. Free Bag or Bagpackers (Tas Training).
7. Softfile Foto Training
8. Sertifikat Pelatihan.
9. Souvenir Exclusive.
